These Apex Garden Storage Buildings are not Built Down to a Price
But to an Unbeatable Standard

We have been selling the Diamond Barnham Heavy Duty wooden workshops and garden storage buildings for over 14 years and they are probably some of the best garden workshops available to buy. Everything about them is right from the heavy duty floor, to the solid 2×2 framework, to the terrific eaves (the lowest part of the workshop) height of over 6ft 3in and with doors which would not look out of place on a barn. You really need to see them appreciate how good they are. And you can at our garden workshops display site near Guildford and Farnham. It’s well worth a visit just to see these buildings.

Fully Bespoke Wooden Garden Workshop to Meet Your Exacting Requirements Including Combination Sheds Workshops

Besides the superb specifications these Diamond Barnham heavy duty workshops are available in more or less any size to suit YOU. Besides that, the positioning of the doors and windows again can be to your bespoke requirements. Extra or no windows, that’s fine, extra door, a wider door of half glass door – again no problem. You may want to use these garden workshops as two separate buildings. Specify a partition and extra doors and you have two garden workshops in one. Much tidier than two separate buildings.

View These Diamond Barnham Heavy Duty Workshops Before Buying

The internet is a wonderful thing and allows you to find no end of different products and this includes garden workshops and wooden buildings. The drawback is those very few companies selling on the ‘web’ will give you the opportunity to see what you are buying. In an ideal world, you could be convinced that everyone is wonderful and you can be sure you will get what you think you have ordered BUT how can you be sure? You can’t! So you can either buy from garden workshop companies who display their buildings for close examination or you can take a chance and hope. Even if you don’t view a wooden workshop for sale beforehand, the fact that you can give you confidence in that particular company. Take a look at our display site near Guildford and buy with ‘Peace of Mind’ included.

Product Description

Sizes from 8×6 to 30×16 Apex
Quality Redwood Timber
Solid Heavy Duty T&G Floors as Standard
FREE Fitting of Garden Workshops
FREE Dipped Treatment
Barn Like Doors as Standard.
Proper Glass NOT cheap perspex
2″ x 2″ Timber Framing As Standard
Great Workshops Eaves Height of 6ft 3in.
Fully Bespoke Workshops ALL Sizes Made
All Workshops Have Rust Resistant Fittings
Garden Workshops Display for you to View
Garden Man Caves Coach Screwed Together
Can be Made Less Than 2.5m High Overall
Lining & Insulation Option for All Year Round Use
Garden Workshops Timber Subframes Built
Prices for following sizes are normally online. Other sizes by request.
6×4 | 6×5 | 6×6 | 7×4 | 7×5 | 7×6 | 7×7 | 8×4 | 8×5 | 8×6 | 8×7 | 8×8 | 9×4 | 9×5 | 9×6 | 9×7 | 9×8 | 9×9 | 10×4 | 10×5 | 10×6 | 10×7 | 10×8 | 10×9 | 10×10 | 11×4 | 11×5 | 11×6 | 11×7 | 11×8 | 11×10 | 12×4 | 12×5 | 12×6 | 12×7 | 12×8 | 12×9 | 12×10 | 12×12 | 14×8 | 14×10 | 14×12 | 15×8 | 15×10 | 15×12 | 16×8 | 16×10 | 16×12 | 18×8 | 18×10 | 18×12 | 20×8 | 20×10 | 20×12 | 22×8 | 22×10 | 24×8 | 24×10 | 28×8 | 28×10

Sizes:	Size of apex garden workshops available are from 6×4 right up to 28×14 and larger. Widths from 4′, 5′, 6′, 7′, 8′, 9′, 10′, 11, 12 & 14′ but other sizes of workshops can be made so please ask if you need any other size.
Cladding:	These apex wooden workshops are clad in T&G Shiplap which is 19mm (15mm finished thickness) thick. This is Redwood deal not cheap whitewood. Treated externally as standard. Coach screwed together construction.
Framework:	50 x 50mm thick (2″ x 2″ nominal) as standard. Effectively thicker in corners when erected (about 70 x 45mm)
Designs:	These are made with an Apex or gable roof. Sometimes known as a ‘v’ shaped roof, pointed roof, ‘saddle back’, pitched roof or angled roof. If you are looking for a pent roof (single slope) then take a look on this page.
Roofs:	These apex roofed workshops are made from solid 16mm (12mm finished thickness) T&G timber and covered with heavy green mineral roofing felt. (no chipboard, sterling board, OSB board or sheet material – as these are unsuitable for outdoor use.)
Floors:	As standard there is an extra strong heavy duty ¾” v313 grade moisture resistant particular boarded floor set on 50 x 45mm (2×2 nominal) pressure impregnated joists for long life.
Doors:	Fully Framed barn like joinery quality heavy duty Doors as standard. One pair of fully boarded doors hung on two pairs 23″ heavy duty door bands, mortice lock and lever furniture on wooden workshops 8′ wide and 8′ long and over and two tower bolts. A single fully boarded door on the smaller sectional buildings, (i.e. workshops less than 8ft wide across the gable end) Beware of garden workshops doors with NO bracing.
Windows:	Workshops windows are made from 3mm clear horticultural glass bedded in clear silicone. (Not cheap scratchable plastic or perspex). All apex garden workshops include at least one opening window, which is top hung with 2 t-hinges and one casement stay. Option for toughened – laminated – wired glass if you choose.
Corner Strips:	The attention to detail on these apex garden workshops extends to ‘Wrap Around’ corner strips for extra protection to the end grain of the timber and for a smarter finish. A small touch but shows a lot of thought has gone into these buildings.
Height:	Internal eaves height is a generous 194m (76½in) eaves on all workshops. Ridge height is from 229cm (89in) to 260cm (102in) on buildings up to 12ft wide. Optional extra height if required. Internal heights quoted NOT external which most firms quote)
Treatment:	All garden workshops and sectional buildings are DIPPED treated with a high quality spirit based timber preservative free of charge. (NOT washed out water based treatment).
Nails:	All fittings and nails are all rust resistant to ensure long lasting good appearance to your workshop. NO staples are used as these are not suitable for a quality heavy duty building.
Insulation:	For all year round use you could consider our option for lining and insulation. Cooler in Summer. Warmer in Winter.
Installation:	All our apex wooden garden workshops and sectional buildings are assembled FREE of charge. All you need to do is to provide a solid level concrete or paving slab base or timber decked area, or possibly could be built on your timber bearers. Optionally, we have an option for building a timber raft for you. Buildings are secured using coach screws for ease of taking them down again if you decide to move.
Delivery:	There is no charge for delivery within Diamond standard delivery area but these apex garden workshops can be delivered in some areas, outside of the free delivery area, for a surcharge.
Bespoke:	Any size apex garden workshop or garden storage building to suit and can be made with extra doors, windows or partitions. If not sure please contact us for your personal quote
Optional Extras:	These include double or wider doors, extra windows, georgian windows, extra height, lining and insulation, partitions, toughened – laminated – wired glass etc – please ask.
Support UK:	These Diamond Barnwell Garden UK Wooden Workshops for sale are made in the UK by experienced craftsmen. Back our British workers.
Sizes:	Unless specified as finished size then sizes quoted are before machining which reduces the size quoted by about 3mm. BEWARE. Many garden workshops manufacturers quote BEFORE machining sizes making them APPEAR larger – don’t be fooled.

Types and Styles of Garden Shed and Choosing the Right One

When buying a garden shed it’s important that you have a building which will suit you and your garden so rather than compromising we offer a very large range of styles which should suit all situations. However, if our standard styles of sheds don’t fit YOUR bill please let us know and we will endeavor to accommodate you. After all, it is YOUR new shed so you should call the shots, so to speak.

We have a simple system for styling. The first letter is the first letter of the supplier’s name (i.e. D for Diamond, P for Platinum etc). The second letter is the type of roof so A for Apex and p for Pent. The final letter is the actual model.

Model PA ( = 1st letter of supplier’s name)

Model *PA is a pent shed which has the door on the short pent end and the windows on the left hand side as you go in the shed. This left hand side is the HIGH side the shed. The number of windows varies according to the size of the building

Model PB ( = 1st letter of supplier’s name)

Model *PB is a pent building where the door and windows are both on the same HIGH side of the shed. The door is set to the RIGHT and the window to the LEFT. There are no door or windows on the pent end. The size of the shed will determine how many windows there will be.

Please note that these pictures only reflect examples of the layouts

Model PC ( = 1st letter of supplier’s name)

The model *PC have both the door and windows on the HIGH side of the building. The windows are set to the RIGHT with the door alongside to the LEFT. The pent end of the shed is all timber. The number of shed window varies according to the size of the building.

Model PD ( = 1st letter of supplier’s name)

Shed model *PD is a pent style building. This has the door on the PENT end of the building. The window is on the RIGHT hand HIGH side of the shed as you go in the door. The amount of shed window varies according to the size of the unit.

Please note that these pictures only reflect examples of the layouts

Model PE ( = 1st letter of supplier’s name)

This shed model has the door on the short PENT end of the building and the window on the LEFT LOW side of the unit. The number of windows varies depending on the size of the shed.

Model PF ( = 1st letter of supplier’s name)

This model *PF also have the windows on the LOW side as you go in the garden shed. As you go in the door, which goes on the short PENT end, the windows will be on the RIGHT-hand LOW side of there building.

Please note that these pictures only reflect examples of the layouts

Model AI ( = 1st letter of supplier’s name)

This *AI garden shed has an APEX roof and with the door on the APEX end of the building. As you go in the door the windows will be on the LEFT-hand side of the unit. The number of windows varies with the size of the shed.

Model AJ ( = 1st letter of supplier’s name)

This *AJ APEX roofed garden shed has the door on the APEX end of the building. As you go in the shed door the windows will be on the RIGHT-hand side of the unit. The number of shed windows varies with the size of the building.

Please note that these pictures only reflect examples of the layouts

Model AG ( = 1st letter of supplier’s name)

This *AG garden shed has the door and windows on the LOW side of the building with the door set to the RIGHT and the windows to the LEFT, also on the LOW side, as you look at it from outside. Nothing on the APEX ends. Bear in mind that as the door and windows are on the LOW side then the door may be lower than standard.

Model AH ( = 1st letter of supplier’s name)

This *AH APEX roofed garden shed has the door and the windows both on the LOW side of the building. The door is set to the LEFT and the windows to the RIGHT. This is looking at the shed from outside of the building. The number of windows varies according to the size of the shed. Don’t forget that as the door and windows are on the LOW side then the door may be lower than standard.

Please note that these pictures only reflect examples of the layouts

Any Style Made to Suit

Provided the garden shed you would like is square or rectangular then it can be made to suit you. Door and windows in different positions – no problem – no windows – no problem – extra doors or windows – just say the word
