INCLUDING VAT
Free Installation
VISIT OUR DISPLAY SITES
Optional Full Insulation
Made to Suit Your Needs
- 8×6 to 30×12 Transverse Apex Workshops
- Timber & Onduline with Expected 15 Years Life
- Redwood Deal T&G (not Cheap whitewood)
- T&G Timber Boards with Onduline Roofs on Top
- Heavy Duty Robust T&G Floors
- FREE Fitting (green delivery areas) of Garden Workshops
- Pressure Treated T&G Solid Walls and Floors
- Heavy Barn Like Doors With Security Key Lock.
- Toughened Glass NOT cheap plastic or perspex
- 70 x 33mm thick (3″ x 1½” nominal) Framework
- 1.85m (73in) Min Internal Lower Eaves Height
- Any Size Bespoke Workshop No Problem
- Galvanised Nails Used on All Man Cave Workshops.
- Wooden Workshops Display for Viewing
- Screwed Together Inside the Garden Workshop
- Feature of Less Than 2.4m High Overall
- Lining & Insulation Option for All Year Round Use
- Timber Workshops Subframes Built
- Prices for following sizes are normally online. Other sizes by request.
8×6 | 10×6 | 12×6 | 14×6 | 16×6 | 18×6 | 20×6 | 8×8 | 10×8 | 12×8 | 14×8 | 16×8 | 18×8 | 20×8 | 6×10 | 8×10 | 10×10 | 12×10 | 14×10 | 16×10 | 18×10 | 20×10 | 6×12 | 8×12 | 10×12 | 12×12 | 14×12 | 16×12 | 18×12 | 20×12 | 8×14 | 10×14 | 12×14 | 14×14 | 16×14 | 18×14 | 20×14 | 8×16 | 10×16 | 12×16 | 14×16 | 16×16 | 18×16 | 20×16 | 6×8 | 6×14 | 6×16 | 6×18 | 6×20 | 8×12 | 8×14 | 8×16 | 8×18 | 8×20 | 10×12 | 10×14 | 10×16 | 10×18 | 10×20 | 12×14 | 12×16 | 12×18 | 12×20
Cladding: | Normally clad in T&G Shiplap, with standard thickness being 19mm nominal (15mm finished size) which is thicker tham most other. Also available in 20mm Loglap T&G cladding OR 23mm to 6mm Rebated & Lined Weatherboard on these sectional buildings. All timber is Redwood deal not cheap inferior whitewood. Tanalised pressure treated as standard with 15 year minimum expected life against rotting. Screwed together construction. |
Framing: | Standard Timber workshops framework size is 70 x 33mm thick (3″ x 1½” nominal) on all buildings. Effectively thicker in corners when erected. All framework screwed together in corners, not just nailed together. Diagonal bracing in all corners for long term stability. Fully pressure treated. |
Designs: | These Platinum Fareham apex garden workshops are made with an apex or gable roof. Other names for this style of roof is ‘v’ shaped roof, pointed roof, ‘saddle back’, pitched roof or angled roof. If you require a pent roof (single slope) then take a look on this page or a standard apex roof take a look on this page. |
Roofs: | These Fareham apex roofed workshops are made from solid 19mm (15mm finished thickness) T&G timber and then covered with the superb Onduline roofing sheets. These roof sheets are designed for very long life with expected 15 years worry free time against leaking. (no chipboard, sterling board, OSB board or sheet materials are used – as these are unsuitable for outdoor use.) Option for gutters and downpipes to conserve that precious water for your garden. Vents added in the soffits (underside of the roof) to allow for free flow of air. Option for green mineral felt, if you choose. |
Floors: | The extra strong heavy duty floor on these Fareham apex garden workshops are made from 19mm (15mm finished size) T&G timber boards set on 50 x 50mm (2×2 nominal) pressure impregnated joists for long life. |
Doors: | Fully Framed barn-like joinery-quality framed, ledged and braced 44mm thick heavy-duty double doors as standard. One pair of fully boarded doors hung on heavy duty stainless steel security butt hinges with the doors being made of hemlock and set in a framed design with heavy duty composite cill and complete with a long throw security bolt (no cost option to switch to a 5-lever mortice lock with lever handle.) Beware of garden workshops doors with NO bracing. Double door size is 1.5 x 1.78m (5ft x 5ft 10in). Clear height through doors is 1.7m (5ft 7in) Option for taller doors on some models. |
Windows: | 3mm clear TOUGHENED glass is used in these superb workshops windows. (No cheap scratchable plastic or perspex). All these Fareham apex garden workshops include at least one opening window, which is top hung with 2 t-hinges and one casement stay. The number of windows varies according to the size of the building. Option for security windows or bars in the windows. |
Corner Strips: | These Platinum Fareham apex garden workshops are finished off with ‘Wrap Around’ corner strips for extra protection to the end grain of the timber and for a smarter finish. This is just one of the many small features which goes into these buildings but shows that a lot of thought has gone into these superb buildings. |
Height: | Internal eaves height is a generous 1.85m (73in) eaves on all sectional buildings. Normal ridge height is at least 2.28m (89 inches) which is less than 2.5m if you have planning issues. Please check before ordering if heights are crucial in connection with planning. (Internal heights quoted NOT external which most firms quote) |
Treatment: | All these garden workshops walls, framing and floors come complete with pressure treated tanalised timber as standard. Although the timber is protected against rotting it’s important that you apply a coat of waterproof treatment within 3 months of delivery to ensure the fullest life for your new building. |
Nails: | All fittings and nails are all rust resistant (galvanised) to ensure long lasting good appearance to your garden workshop. NO staples are used as these are not suitable for a quality heavy duty building. |
Insulation: | These garden workshops can be optional lined and insulated for all year round use. Cooler in Summer. Warmer in Winter. |
Installation: | All our Transverse apex garden workshops are fitted FREE of charge in our green delivery areas. All you need to do is to provide a solid level concrete or paving slab base or timber decked area, or maybe it could be built on your timber bearers. There is also an option for building a timber raft for you. Buildings are assembled using screws for ease of taking them down again if you decide to move. |
Optional Extras: | These include double or wider doors, extra windows, extra height, lining and insulation, partitions, gutters and downpipes etc – please ask. |
Delivery: | Free delivery is include for most of England (mainland). Outside of this free delivery area it is often possible to deliver and erect these apex garden workshops for a small surcharge. |
Specials: | Any size or design of apex garden workshop or sectional timber building to suit and can be made with extra doors, windows or partitions. If not sure please contact us for your personal quote for your precise needs. |
Viewing: | Option to view these superb garden buildings before buying so you can inspect at first hand the high quality of the materials used and the construction methods. Show sites near Farnham and Guildford in Surrey. Please check which models are on site before visiting to avoid disappointment. |
Support UK: | These Platinum Fareham apex Heavy Duty Garden Workshops are made in the UK by experienced craftsmen. Back our British workers. |
Sizes: | Unless specified as finished size then workshop sizes quoted are before machining which reduces the size quoted by about 3mm. BEWARE. Many garden workshops manufacturers quote BEFORE machining sizes making them APPEAR larger – don’t be fooled. Prices for following sizes are online. Other sizes by request. |
